TAP100

WI-FI ACCESS POINT

TAP100 is the first-ever Teltonika Networks Access Point, perfect for strengthening Wi-Fi coverage in small enterprise and commercial spaces. This PoE-in access point can be powered by active PoE devices via its RJ45 port and was designed with simplicity and ease of installation in mind.

PoE-IN

Can be powered by PoE devices via RJ45 port

SLEEK DESIGN

UV-stabilized plastic housing that blends in with its environment

EASY INSTALLATION

Integrated mounting bracket for easy ceiling setup

RMS MANAGEMENT

Free access to RMS Management for 24 months

3D MODEL

PRODUCT GALLERY

MORE PHOTOS

INTRODUCTION VIDEO

QSG VIDEO

Features

Downloads

Ordering

Support

Wireless

Wireless mode

IEEE 802.11b/g/n (Wi-Fi 4) with data transmission rates up to 300 Mbps
WiFi security

WPA2-EAP/WPA3-EAP Mixed Mode, WPA3-EAP, WPA2-PSK/WPA3-SAE Mixed Mode, WPA3-SAE, OWE, WPA-PSK/WPA2-PSK Mixed Mode, WPA2-PSK, WPA2-EAP; AES-CCMP, TKIP, Auto Cipher modes, client separation
SSID/ESSID

SSID stealth mode and access control based on MAC address
WiFi users

Up to 100 simultaneous connections

Ethernet

Ethernet

1 x RJ45 port 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover

Network

Network protocols

TCP, UDP, IPv4, IPv6, ICMP, HTTP, HTTPS, SSL v3, TLS, ARP, SSH, DHCP client, SMNP

Security

Authentication

Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & Login attempts block
VLAN

Tag based VLAN separation

Monitoring & Management

WEB UI

HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log
FOTA

Firmware update from server, automatic notification
SSH

SSH (v1, v2)
SNMP

SNMP (v1, v2, v3), SNMP Trap
JSON-RPC

Management API over HTTP/HTTPS
RMS

Teltonika Remote Management System (RMS)

System Characteristics

CPU

Mediatek MIPS 24Kc 580 MHz
RAM

64 MB, DDR2
FLASH storage

16 MB, SPI Flash

Firmware / Configuration

WEB UI

Update FW from file, check FW on server, configuration profiles, configuration backup
FOTA

Update FW
RMS

Update FW/configuration for multiple devices at once
Keep settings

Update FW without losing current configuration

Firmware Customization

Operating system

RutOS (OpenWrt based Linux OS)
Supported languages

Busybox shell, Lua, C, C++
Development tools

SDK package with build environment provided

Power

Connector

RJ45 Socket
Input voltage range

44.0 – 57.0 V
PoE standards

802.3af PoE Class 1
Power consumption

< 2 W Max

Physical Interfaces

Ethernet

1 x RJ45 ports, 10/100 Mbps
Status LEDs

1 x Power LED (can be turned off from web-UI)
Antennas

2 x Internal for 2.4 GHz Wi-Fi
Reset

Reboot/User default reset/Factory reset button

Physical Specification

Casing material

UV stabilized plastic
Dimensions

Ø 158 mm x 30 mm
Weight

190 g
Mounting options

AP Mounting Bracket (for ceiling mount)

Operating Environment

Operating temperature

-40 °C to 75 °C
Operating humidity

10% to 90% non-condensing
Ingress Protection Rating

IP30

Regulatory & Type Approvals

Regulatory

CE, UKCA, CB, FCC, IC, WEEE

EMI Immunity

Standards

EN 55032:2015+A11:2020
EN 55035:2017+A11:2020
EN 61000-3-3:2013+A1:2019+A2:2021
EN IEC 61000-3-2:2019+A1:2021
EN 301 489-1 V2.2.3
EN 301 489-17 V3.2.4
ESD

EN 61000-4-2:2009
RS

EN IEC 61000-4-3:2020
EFT

EN 61000-4-4:2012
Surge protection

EN 61000-4-5:2014+A1:2017
CS

EN 61000-4-6:2014
DIP

EN IEC 61000-4-11:2020
