TSW304
3D MODEL
ETH
4 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
IEEE 802.3 series standards
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
Bandwidth (Non-blocking)
8 Gbps
Packer buffer
128 KB
MAC address table size
2K entries
Jumbo frame support
9216 bytes
Connector
2-pin industrial DC power socket
Input voltage range
7 - 57 VDC; 9 - 40 VAC
PoE (passive)
Possibility to power up through ETH1 ports, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC
Power consumption
Idle: 0.26 W / Max: 1.44 W
Ethernet
4 x RJ45 ports, 10/100/1000 Mbps
Status LEDs
8 x ETH status LEDs, 1 x Power LED
Power
1 x 2-pin industrial DC power socket
Other
1 x Grounding screw
Casing material
Aluminium housing
Dimensions (W x H x D)
102 x 25 x 81.5 mm
Weight
210 g
Mounting options
Integrated DIN rail bracket, wall mount, flat surface (additional kit needed)
Operating temperature
-40 °C to 75 °C
Operating humidity
5% to 95% non-condensing
Ingress Protection Rating
IP30
Regulatory
CE, REACH, RoHS, WEEE, UKCA, FCC, IC, CB, RCM
Standards
EN IEC 62368-1:2020+A11:2020
IEC 60068-2-6:2007 Environmental testing - Part 2-6
IEC 60068-2-27:2008 Environmental testing - Part 2-27
IEC 60068-2-31:2008 Environmental testing - Part 2-31
